The Fink truss, the ancestor of the inverted Fink truss, was patented in 1854 by Albert Fink, a German engineer[4][10]. Fink designed his truss bridges primarily for American railroads, including the Baltimore and Ohio and the Louisville and Nashville Railroads[4]. The first Fink Truss bridge was constructed in 1852 by the Baltimore and Ohio Railroad to span the Monongahela River in Fairmont, West Virginia[4]. This bridge consisted of three spans, each 205 feet long, and was the longest iron railroad bridge in the United States at the time[4].
The Fink truss design was widely used from 1854 through 1875 and held world records for its time[4]. Notable examples include the Green River Bridge near Munfordville, Kentucky, and the first bridge to span the Ohio River, which included a 396-foot span built between 1868 and 1870[4]. The Fink truss is identified by multiple diagonal members projecting down from the top of the end posts at various angles, extending to the bottom of each of the vertical members[4]. Many Fink trusses do not include a lower chord, giving the bridge a saw-toothed appearance[4].
An inverted Fink truss is a variation of the traditional Fink truss, distinguished by having a bottom chord without a top chord[4]. This design is often used in pedestrian bridges and as roof trusses in building construction[4]. The inverted Fink truss differs from its ancestor through its statically indeterminate behavior[1].
One notable example of an inverted Fink truss bridge is the Grand Large footbridge in Dunkirk, France. This bridge combines the characteristics of a truss girder and a cable-stayed bridge[1]. The inverted Fink truss design adapts the lever arm between the crossing of the cable and deck, with the height of the masts following a parabolic curve[1]. The height of the pylons is 23 meters above deck level, maintaining a height-to-span ratio typical of cable-stayed bridges[1]. The masts are located on each side of the deck, maximizing space for pedestrians and limiting transverse forces in the masts[1].
The inverted Fink truss is designed to support a structure from below, using a series of beams and cables arranged in a triangular pattern[7]. The beams support the weight of the structure, while the cables keep the beams in place[7]. This design is particularly useful in structures where there is a need to free up internal space, such as stadiums, bridges, and roofs with large spans[7].
Inverted trusses can be configured in a range of sizes, with typical spans between 30 to 60 feet (9.1 to 18.3 meters) and overall heights of 5 to 20 feet (1.52 to 6.1 meters)[7]. The thickness of wood trusses is commonly 1.5, 3, or 4.5 inches (3.8, 7.6, 11.4 cm)[7]. Trusses typically have a pitch ratio between 1:3 to 1:6[7].
1. Moody Pedestrian Bridge, University of Texas at Austin: The Moody Pedestrian Bridge is a unique inverted Fink truss bridge that connects two buildings at the Moody College of Communication[2][5]. Spanning over Dean Keaton Street, this bridge is characterized by slender steel towers of varying height and scale[2]. DETAN Tension rods connect the steel towers to the bridge structure, providing an elegant look[2]. The bridge is 300 feet long, with a 65-foot high tower serving as a gateway to the university campus[2]. It also features integrated aesthetic lighting in its stainless steel railings for an attractive nighttime appearance[2].
2. Grand Large Footbridge, Dunkirk: The Grand Large footbridge in Dunkirk, France, exemplifies the integration of truss girder and cable-stayed bridge designs[1]. Its inverted Fink truss structure adapts the lever arm between the cable crossing and the deck, with masts following a parabolic curve[1]. The pylons reach 23 meters above the deck, and the mast spacing is 16 meters, optimizing stay inclination[1].
3. The world's longest span inverted fink truss bridge: Recently recognized by Guinness World Records[8].
Fink design trusses are used today for pedestrian bridges and as roof trusses in building construction in an inverted form where the lower chord is present and a central upward projecting vertical member and attached diagonals provide the bases for roofing[4].
- Efficient use of materials[7]
- Aesthetically pleasing designs[2]
- Suitable for long spans[7]
- Provides open spaces underneath the structure[7]
- Complex structural analysis required[1]
- Susceptible to buckling under heavy loads
- High initial construction costs
The inverted Fink truss bridge represents a compelling synthesis of historical engineering principles and contemporary design innovation. Originating from the Fink truss patented by Albert Fink in 1854, the inverted variant has evolved to meet modern structural needs, particularly in pedestrian bridges and roof construction. Distinguished by its bottom chord without a top chord, this design offers unique aesthetic and spatial advantages, making it suitable for long spans and structures requiring open spaces underneath. Notable examples such as the Moody Pedestrian Bridge in Austin, Texas, and the Grand Large footbridge in Dunkirk, France, showcase the versatility and visual appeal of this structural form. While the inverted Fink truss bridge presents challenges such as complex structural analysis and susceptibility to buckling, its efficient use of materials and distinctive appearance make it a valuable option in modern bridge design. As engineering continues to evolve, the inverted Fink truss bridge stands as a testament to the enduring legacy of structural innovation, blending historical precedent with contemporary application.
The main difference lies in their geometry. A Fink truss has diagonal members projecting down from the top of the end posts, often without a lower chord, giving it a saw-toothed appearance[4]. An inverted Fink truss, on the other hand, has a bottom chord without a top chord, effectively inverting the structure[4].
Inverted Fink trusses are commonly used in pedestrian bridges, roof trusses, and structures requiring large open spaces underneath, such as stadiums[7]. They are also utilized in situations where an aesthetically pleasing design is desired[2].
The primary advantages include efficient use of materials, an aesthetically pleasing design, suitability for long spans, and the provision of open spaces beneath the structure[7][2]. These features make it a versatile option for various structural applications.
Yes, notable examples include the Moody Pedestrian Bridge at the University of Texas at Austin and the Grand Large footbridge in Dunkirk, France[2][1]. The Moody Pedestrian Bridge is known for its slender steel towers and aesthetic lighting, while the Grand Large footbridge combines truss girder and cable-stayed bridge designs.
Some challenges include the need for complex structural analysis, susceptibility to buckling under heavy loads, and potentially high initial construction costs[1]. Careful engineering and design considerations are necessary to mitigate these challenges.
